Barracuda Max S6 Detail
Filename:
Barracuda Max S6 Detail.dwg

This document is the Barracuda Max S6 Detail. The stormwater treatment plan view and section views with dimensions included.
The stormwater treatment unit shall be an inline unit capable of conveying 100% of the design peak flow. It will remove 80% of the suspended solids on an average aggregate removal basis.
The section view A-A shows the frame and cover, integrated internal weir, inlet/outlet, deflector plate, bowl, fin array and Barracuda Max bowl insert.
The plan view shows the Barracuda S6 concrete manhole, frame & cover/grate, inlet and outlet pipe.
4 notes with additional information provided.
