Duraslot & Duraslot XL Track & Field Layout

Filename:
Duraslot & Duraslot XL Track & Field Layout.pdf

Duraslot & Duraslot XL Track & Field Layout

This document shows the Duraslot & Duraslot XL Track & Field Layout. A detail of the Duraslot track & field with tables and notes provided.

The Duraslot track & field detail shows the 330’ linear drain lengths, and location of the nyloplast basin as an outlet/cleanout structure around the track.

One table shows the typical bill of materials in quantity, material and total. A 2nd table notes the typical burial depths for sloped linear drains.

Notes refer to details 1464A or 1464C for backfill design locations. This detail does not account for pipe and fittings and all dimensions are reference only.
