This document is the 8" - 30" Minimum Angle Between Add-A-Branch Adapters Nyloplast Detail. An illustration with chart dimensions shown.

The 8" - 30" Minimum Angle Between Add-A-Branch Adapters chart does not apply when using envirohood. The chart shows the adapter sizes for 8” basin, 10” basin, 12” basin, 15” basin, 18” basin, 24” basin, 30” basin and 36” basin.

The illustration shows the 18” and 36” drain basin, 2 add-a-branch adapters and the minimum angle.
