48" Polypropylene Basin Connection Options
48" Polypropylene Basin Connection Options.dwg
This document is the 48" Polypropylene Basin Connection Options. An ADS split coupler and Inserta-TEE detail are shown.
The ADS split coupler detail shows the ADS premium split coupler and the plain-end stub.
The Inserta-TEE detail show the Inserta-TEE watertight joint and the Inserta-TEE bell installed during fabrication. The Inserta-TEE fitting can also be installed in the field.
