1410A Duraslot Coupler Band
Filename:
1410A Duraslot Coupler Band.pdf

This document shows the 1410A Duraslot Coupler Band. Details of the Duraslot coupler with dimensions and dimension tables provided.
The top detail shows the end view/side view of the ST cleated coupler for 4” pipe diameter. The 2nd detail shows the end view/side view of the Bell-Bell coupler for for 6” pipe diameter. The 3rd detail shows the end view/side view of the split coupler for 8”-36” pipe diameter.
The 2.5” slot riser coupler band dimension table shows pipe in mm, various height and length dimensions for H/O/F/W/A/B and the product number.
The 6” slot riser coupler band dimension table shows pipe in mm, various height and length dimensions for H/O/F/W/A/B and the product number.
The variable slot riser coupler band dimension table shows pipe in mm, various height and length dimensions for H/O/F/W/A/B and the product number.
