MC-3500 10" (250 mm) StormTech Inspection Port Detail
Filename:
MC-3500 10" (250 mm) StormTech Inspection Port Detail.dwg
MC-3500 10" (250 mm) StormTech Inspection Port Detail.
This document is the MC-3500 10" (250 mm) Inspection Port Detail. A cross section of the inspection port detail is shown.
The cross section of the MC-3500 Inspection port shows 18” minimum width, the concrete collar, pavement, concrete slab, 15” nyloplast inline drain body with solid hinged cover, 10” SDR 35 pipe and the 10” inserta TEE which is to be centered on corrugation crest. The MC-3500 chamber is positioned underneath.
