This document is the 207A 12-30 HP Storm Compression (Cast-In) Structure Connection with Sleeve or PVC Adapter Detail. Details and charts provided.

The first detail shows the Compression (Cast-In) resilient structure connection, Dual Wall HP Storm and the sleeve MH adapter.

The second detail shows the Compression (Cast-In) resilient structure connection, Dual Wall HP Storm and the Nyloplast PVC manhole adapter.

The chart features the Sanitite HP Sleeve Manhole Adapter with values for pipe size, ADS Product Codes, A-LOK Premium and Press Seal/Econoseal.

A second chart features the Nyloplast PVC Manhole Adapter with values for pipe size, ADS Product Codes, A-LOK and Press Seal Systems for Econoseal and Kwik Seal.

Notes recommend performance is highly dependent on installation. Manhole gasket must be uniformly seated around structure adapter.
