12" - 30" Diameter Fabricated "Water Tight" "Gasket End" Double Manifold (HDPE Manifolds Fittings)

Filename:
12" - 30" Diameter Fabricated "Water Tight" "Gasket End" Double Manifold (HDPE Manifolds Fittings).pdf

12" - 30" Diameter Fabricated "Water Tight" "Gasket End" Double Manifold (HDPE Manifolds Fittings)

This document is the 12" - 30" Diameter Dual Wall Fabricated “Water Tight” “Gasket-End” Double Manifold (HDPE Manifolds Fittings). A diagram with table provided.

The dual wall fabricated “Water Tight” “Gasket-End” Double Manifold 36" - 60" diameter is shown in a diagram that shows A/B/C/D/S dimensions.

A table with the information for part number, pipe size and A/B/C/D/S sizes is provided.

All fittings dimensions are for reference only.
