12" Bronze Locking Grate Assembly Nyloplast Detail

Filename:
12" Bronze Locking Grate Assembly Nyloplast Detail.dwg

12" Bronze Locking Grate Assembly Nyloplast Detail

This document is the 12" Bronze Locking Grate Assembly Nyloplast Detail. It shows illustrations with descriptions.

The side view illustrations show the 12” grate frame & 12” Bronze grate with ¼-20 x 1 ¾” long hex bolt brass in 2 places. The top down view shows the grate with drill thru position and the frame drill thru thread position.

A note states that the location of locking device may vary.
