Potable Water Service Pipe (IPS) Specification

The specification describes ADS Potable Water Service Tubing (IPS) pipe SIDR 19, SIDR 15, SIDR 11.5, SIDR 9 and SIDR 7 for use in potable water service applications.

The information includes pipe requirements, material properties, disinfection maintenance, installation and tubing properties information.

ADS potable water service tubing meets ASTM D2239, NSF/ANSI Standards 14 and 61 and AWWA C901 requirements and the pipe’s dimensions meet ID controlled Iron Pipe Size (IPS) standards.

The material properties are high-density polyethylene conforming to the minimum requirements of cell classification 445574C or 445574E described in ASTM D3350. The resin’s material designation code is PE4710 as designated by the Plastic Pipe Institute.

The active chlorine content of the disinfecting solutions shall not exceed 12% and must be flushed from all lines within the system. Industry accepted procedures, like ANSI/AWWA C651 Disinfecting Water Mains, should be followed for both new and repaired reclaimed water lines.

Installation is similar to other flexible tubing/pipe products. Methods include direct bury, plowing or pulling are applicable per local, state or federal guidelines.

The tubing properties table shows outside diameter, wall thickness, pressure rating and weight for ½”, ¾”, 1”, 1 ¼”, 1 ½” and 2” pipe for SIDR 19, SIDR 15, SIDR 11.5, SIDR 9 and SIDR 7.
